MSI 微星 MAG 272UP QD-OLED E16 26.5 吋 4K 165Hz QD-OLED 電競螢幕
MSI MAG 272UP QD-OLED E16 26.5-inch 4K 165Hz QD-OLED Gaming Monitor
產品介紹
26.5 吋 4K QD-OLED 面板以細緻像素呈現遊戲、影音與工作內容，165Hz 更新率及 0.03ms GtG 反應時間提供流暢動態。第四代 Tandem QD-OLED 結合 EL Gen 3 技術，適合重視影像細節與桌面空間的配置。
產品特色
Uniform Luminance 支援 HDR 曲線調整；OLED Care 2.0 提供像素位移與靜態畫面保護。通過 DisplayHDR True Black 400、ClearMR 9000 認證，支援 PIP／PBP。USB-C 提供影像輸入與 15W PD 供電。
主要規格
• 顯示技術：QD-OLED；10-bit、10.7 億色；防反射表面
• 對比／視角：1,500,000:1（典型值）；可視角度 178°／178°
• 面板／解析度：26.5 吋平面；3840 × 2160；16:9
• 更新率／反應時間：165Hz；0.03ms GtG；VRR 48–165Hz
• 亮度：SDR 250 nits；HDR 峰值 1000 nits
• 色域：Adobe RGB／DCI-P3／sRGB：98%／99%／138%（CIE1976）
• 影像連接埠：HDMI 2.1 ×2、DisplayPort 1.4a HBR3 ×1、USB-C DP Alt Mode ×1（PD 15W）
• 音訊／多工：耳機輸出 ×1；PIP／PBP；不支援 KVM
• 支架／壁掛：升降 110mm；俯仰 -5°～20°；VESA 100 × 100mm
• 尺寸／重量：含支架 611.1 × 241.9 × 532.8mm；不含支架 611.1 × 69.3 × 357.2mm；淨重 7.7kg
• 同步技術：NVIDIA G-SYNC Compatible、AMD FreeSync Premium Pro
• 電源：100–240V、50／60Hz
• 保固：3 年（包含面板烙印），依原廠保固條款。
使用與安裝
固定底座或相容的 VESA 支架後，再連接電源及影像線。高更新率需由顯示卡、線材與所選介面共同支援，並在系統顯示設定中選擇。USB-C 影像需裝置支援 DP Alt Mode。依 OLED Care 提示完成面板保養，避免長時間固定顯示高亮度圖樣；清潔時勿對面板施壓。HDR 峰值不等於全畫面持續亮度。
Overview
The 26.5-inch 4K QD-OLED panel presents detailed gaming, media and desktop content at 165Hz with 0.03ms GtG response. Fourth-generation Tandem QD-OLED with EL Gen 3 technology suits compact setups that prioritize image detail.
Features
Uniform Luminance adjusts HDR curves, while OLED Care 2.0 provides pixel shifting and static-image protection. Certifications include True Black 400 and ClearMR 9000. PIP/PBP is supported; USB-C handles video and 15W power delivery.
Specifications
Display: QD-OLED; 10-bit, 1.07 billion colors; anti-reflection surface
Contrast/viewing: 1,500,000:1 typical; viewing angles 178°/178°
Panel/resolution: 26.5-inch flat; 3840 × 2160; 16:9
Refresh/response: 165Hz; 0.03ms GtG; VRR 48–165Hz
Brightness: SDR 250 nits; HDR peak 1000 nits
Gamut: Adobe RGB/DCI-P3/sRGB: 98%/99%/138% (CIE1976)
Video: HDMI 2.1 ×2; DisplayPort 1.4a HBR3 ×1; USB-C DP Alt Mode ×1, 15W PD
Audio/multitasking: Headphone output ×1; PIP/PBP; no KVM
Stand/mount: 110mm height; tilt -5° to 20°; VESA 100 × 100mm
Dimensions/weight: With stand 611.1 × 241.9 × 532.8mm; without 611.1 × 69.3 × 357.2mm; net 7.7kg
Sync: NVIDIA G-SYNC Compatible and AMD FreeSync Premium Pro
Power: 100–240V, 50/60Hz
Warranty: 3 years including panel burn-in, subject to manufacturer terms.
Setup and care
Secure the stand or compatible VESA arm before wiring. Select the desired refresh rate in system settings; GPU, cable and input support must match. USB-C video requires DP Alt Mode. Follow OLED Care prompts and avoid prolonged bright static content. Do not press on the panel when cleaning. HDR peak brightness is not sustained full-screen brightness.
