螢幕
MSI 微星 MAG 274QPF E20 27 吋 WQHD 200Hz Rapid IPS 電競螢幕
MSI MAG 274QPF E20 27-inch WQHD 200Hz Rapid IPS Gaming Monitor
產品介紹
MAG 274QPF E20 結合 27 吋 WQHD 解析度、200Hz 更新率與 0.5ms GtG 最小反應時間，適合遊戲與多視窗工作。可升降、旋轉的支架方便調整視線，也能以 USB-C 連接支援的筆電。
產品特色
具備 VESA DisplayHDR 400、Adaptive-Sync、AI Crosshair 與 AI Vision。支援 PIP／PBP，USB-C 提供 DP Alt Mode 影像及 15W PD。130mm 升降及直向旋轉讓遊戲、閱讀和工作模式切換更方便。
主要規格
• 顯示技術：平面 Rapid IPS；防眩光；10.7 億色、10-bit（8-bit + FRC）
• 對比／視角：1000:1；178°／178°
• 面板／解析度：27 吋；2560 × 1440；16:9
• 更新／反應：200Hz；0.5ms GtG（最小值）；VRR 48–200Hz
• 亮度／HDR：SDR 300 nits；VESA DisplayHDR 400
• 色域：Adobe RGB／DCI-P3／sRGB：92%／95%／124%（CIE1976）
• 連接埠：HDMI 2.0b ×2、DisplayPort 1.4a HBR3 ×1、USB-C DP Alt Mode／PD 15W ×1；耳機輸出 ×1
• 輸入上限／多工：DP／USB-C：WQHD 200Hz；HDMI：WQHD 144Hz；PIP／PBP；無 KVM
• 支架／壁掛：升降 130mm；俯仰 -5°～20°；左右 ±30°；垂直旋轉 ±90°；VESA 100 × 100mm
• 尺寸／重量：含支架 613.3 × 227.9 × 404.8mm；不含支架 613.3 × 57 × 365.4mm；淨重 6.8kg
• 電源：100–240V、50／60Hz
安裝與使用
將底座或相容 VESA 支架固定後再接線，確認桌面與支架足以承重。於系統設定選擇所需更新率；顯示卡、線材與輸入介面需共同支援。反應時間最小值與實際使用表現會因模式及設定而異。依環境調整亮度，清潔時使用柔軟布料，避免按壓面板。 USB-C 影像需裝置支援 DP Alt Mode，15W PD 不代表可替所有筆電提供完整充電功率。
Overview
MAG 274QPF E20 combines a 27-inch WQHD panel, 200Hz and a 0.5ms minimum GtG response for gaming and multi-window work. Its adjustable stand and USB-C input support flexible desktop arrangements.
Features
Features include VESA DisplayHDR 400, Adaptive-Sync, AI Crosshair and AI Vision. PIP/PBP supports multiple inputs; USB-C carries DP Alt Mode video and 15W power. Height adjustment and portrait rotation adapt to reading and work.
Specifications
Display: Flat Rapid IPS; anti-glare; 1.07 billion colors, 10-bit (8-bit + FRC)
Contrast/viewing: 1000:1; 178°/178°
Panel/resolution: 27-inch; 2560 × 1440; 16:9
Refresh/response: 200Hz; 0.5ms GtG minimum; VRR 48–200Hz
Brightness/HDR: SDR 300 nits; VESA DisplayHDR 400
Gamut: Adobe RGB/DCI-P3/sRGB: 92%/95%/124% (CIE1976)
Ports: HDMI 2.0b ×2; DP 1.4a HBR3 ×1; USB-C DP Alt Mode/15W PD ×1; headphone output ×1
Input limits/multitasking: DP/USB-C: WQHD 200Hz; HDMI: WQHD 144Hz; PIP/PBP; no KVM
Stand/mount: 130mm height; tilt -5° to 20°; swivel ±30°; pivot ±90°; VESA 100 × 100mm
Dimensions/weight: With stand 613.3 × 227.9 × 404.8mm; without 613.3 × 57 × 365.4mm; net 6.8kg
Power: 100–240V, 50/60Hz
Setup and use
Secure the stand or compatible VESA arm before wiring and check its load capacity. Select the desired refresh rate in system settings; GPU, cable and input must support it. Minimum response figures depend on settings and mode. Adjust brightness for the room and clean gently without pressing the panel. USB-C video needs DP Alt Mode; 15W PD may not fully power a laptop.
