MSI 微星 Modern AM242T 12M 桌上型電腦
MSI Modern AM242T 12M Desktop PC
Modern AM242T 12M 為 MSI 微星桌上型電腦系列。以下依個別 SKU 列出處理器、顯示、記憶體與儲存配置，方便比較適合的版本；各配置分開列示。
產品特色
以各 SKU 的處理器、顯示晶片與記憶體組合選擇所需配置，並核對儲存容量。標示「最高」或「最大」的數值是支援上限，並不代表每個版本的實際配置。
各 SKU 配置
SKU: Modern AM242T 12M-650TW
處理器：Intel Core i5-1240P
顯示晶片：UMA 共享記憶體顯示
記憶體：2x DDR4 SDRAM SO-DIMM 插槽
16GB(8GB*2) DDR4 SDRAM 1600(3200)MHz SO-DIMM
最大 64GB
儲存裝置：512GB (512GB*1) PCIe GEN3x4 不含 DRAM NVMe M.2-2280 M-KEY SSD
螢幕：23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
防眩光
作業系統：Windows 11 Pro
SKU: Modern AM242T 12M-651TW
處理器：Intel Core i5-1240P
顯示晶片：UMA 共享記憶體顯示
記憶體：2x DDR4 SDRAM SO-DIMM 插槽
8GB(8GB*1) DDR4 SDRAM 1600(3200)MHz SO-DIMM
最大 64GB
儲存裝置：512GB (512GB*1) PCIe GEN3x4 不含 DRAM NVMe M.2-2280 M-KEY SSD
螢幕：23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
防眩光
作業系統：Windows 11 Pro
SKU: Modern AM242T 12M-652XTW
處理器：Intel Core i5-1235U
顯示晶片：UMA 共享記憶體顯示
記憶體：2x DDR4 SDRAM SO-DIMM 插槽
8GB(8GB*1) DDR4 SDRAM 1600(3200)MHz SO-DIMM
最大 64GB
儲存裝置：512GB (512GB*1) PCIe GEN3x4 不含 DRAM NVMe M.2-2280 M-KEY SSD
螢幕：23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
防眩光
SKU: Modern AM242T 12M-653TW
處理器：Intel Core i5-1235U
顯示晶片：UMA 共享記憶體顯示
記憶體：2x DDR4 SDRAM SO-DIMM 插槽
8GB(8GB*1) DDR4 SDRAM 1600(3200)MHz SO-DIMM
最大 64GB
儲存裝置：512GB (512GB*1) PCIe GEN3x4 不含 DRAM NVMe M.2-2280 M-KEY SSD
螢幕：23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
防眩光
作業系統：Windows 11 Pro
使用與安裝
使用前請確認完整 SKU 與所需周邊介面相符。將設備放置於穩固、通風的位置，連接適用的電源與周邊後完成作業系統設定；更新適用的系統及裝置驅動程式。記憶體與儲存裝置升級前，先確認該 SKU 的插槽、相容性及維修方式。實際效能受電源模式、散熱與使用情境影響。
The MSI Modern AM242T 12M Desktop PC family is listed below by individual SKU, with separate processor, graphics, memory and storage configurations for comparison.
Features
Choose a configuration by its SKU-specific processor, graphics and memory, then check storage. Values marked up to or maximum are limits and do not imply that every version includes that configuration.
SKU configurations
SKU: Modern AM242T 12M-650TW
Processor: Intel Core i5-1240P
Graphics: UMA
Memory: 2x DDR4 SDRAM SO-DIMM slots
16GB(8GB*2) DDR4 SDRAM 1600(3200)MHz SO-DIMM
Max 64GB
Storage: 512GB (512GB*1) PCIe GEN3x4 w/o DRAM NVMe M.2-2280 M-KEY SSD
Display: 23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
Anti-Glare
Operating system: Windows 11 Pro
SKU: Modern AM242T 12M-651TW
Processor: Intel Core i5-1240P
Graphics: UMA
Memory: 2x DDR4 SDRAM SO-DIMM slots
8GB(8GB*1) DDR4 SDRAM 1600(3200)MHz SO-DIMM
Max 64GB
Storage: 512GB (512GB*1) PCIe GEN3x4 w/o DRAM NVMe M.2-2280 M-KEY SSD
Display: 23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
Anti-Glare
Operating system: Windows 11 Pro
SKU: Modern AM242T 12M-652XTW
Processor: Intel Core i5-1235U
Graphics: UMA
Memory: 2x DDR4 SDRAM SO-DIMM slots
8GB(8GB*1) DDR4 SDRAM 1600(3200)MHz SO-DIMM
Max 64GB
Storage: 512GB (512GB*1) PCIe GEN3x4 w/o DRAM NVMe M.2-2280 M-KEY SSD
Display: 23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
Anti-Glare
SKU: Modern AM242T 12M-653TW
Processor: Intel Core i5-1235U
Graphics: UMA
Memory: 2x DDR4 SDRAM SO-DIMM slots
8GB(8GB*1) DDR4 SDRAM 1600(3200)MHz SO-DIMM
Max 64GB
Storage: 512GB (512GB*1) PCIe GEN3x4 w/o DRAM NVMe M.2-2280 M-KEY SSD
Display: 23.8" (60cm) IPS
1920x1080 (FHD)
178°(H)/178°(V)
Anti-Glare
Operating system: Windows 11 Pro
Setup and use
Check the complete SKU and required peripheral connections before use. Place the device on a stable, ventilated surface, connect compatible power and peripherals, and complete operating-system setup. Install applicable system and device-driver updates. Before upgrading memory or storage, confirm the SKU-specific slots, compatibility and service procedure. Performance depends on power mode, cooling and workload.
