MSI 微星 MAG 274QP QD-OLED X24 螢幕

The MSI MAG 274QP QD-OLED X24 monitor offers the panel and connectivity specifications below. Choose it by screen size, resolution and refresh rate, and match your connection to the stated resolution and refresh-rate limits for each input. Features Panel size: 26.5" Panel type: QD-OLED Panel resolution: 2560 x 1440 (WQHD) Refresh rate: 240Hz Response time: 0.03ms (GtG) HDR support: HDR Ready Full specifications Panel size: 26.5" Active display area (mm): 590.42 (H) x 333.72 (V) Curvature: Flat Panel type: QD-OLED Panel resolution: 2560 x 1440 (WQHD) Pixel pitch: 0.2292 (H) x 0.2292 (V) Aspect ratio: 16:9 Brightness: SDR: 200 HDR: 400 (Typ.) Contrast ratio: 1500000:1 (Typ.) Signal frequency: 384~386.9 KHz(H) / 48 ~ 240 Hz(V) Refresh rate: 240Hz Response time: 0.03ms (GtG) Dynamic refresh-rate technology: Adaptive-Sync HDR support: HDR Ready Video ports: 2x HDMI™ 2.1 (FRL 10G) (WQHD@240Hz) 1x DisplayPort 1.4a (HBR3) Audio ports: 1x Headphone-out Viewing angle: 178°(H) / 178°(V) Adobe RGB / DCI-P3 / sRGB: 98% / 99% / 138% (CIE1976 Standard) Surface treatment: Anti-Reflection Display colors: 1.07B, 10 bits Power: Internal Power Board Power input: 100~240V, 50/60Hz Tilt adjustment: -5° ~ 20° Height adjustment: 0 ~ 110 mm Swivel adjustment: -30° ~ 30° Pivot adjustment: -90° ~ 90° Kensington lock: Yes Carton dimensions (W × D × H): 820 x 169 x 513 mm (32.2 x 6.6 x 20.1 inch) VESA mounting: 100 x 100 mm Variable refresh-rate range: 48~240Hz Console mode: Supported Resolution & Refresh Rate: 1080p: 60Hz and 120Hz 1440p: 60Hz and 120Hz HDMI™ CEC: Supported VRR: PS5 and Xbox Supported Dimensions with stand (W × D × H): 609.3 x 241.9 x 427.1 mm (23.9 x 9.5 x 16.8 inch) Dimensions without stand (W × D × H): 609.3 x 67.1 x 356.2 mm (23.9 x 2.6 x 14.02 inch) Net/gross weight: 6.7 kg (14.7 lbs) / 9.4 kg (20.7 lbs) Accessories: 1x DisplayPort Cable (1.4a), 1x Power Cord (C13), 1x Quick Guide, 4x VESA Wall Mount Screw, 1x Fiber Cloth, 1x Color Report Notes: HDMI™: 2560 x 1440 (Up to 240Hz) DisplayPort: 2560 x 1440 (Up to 240Hz) Support: HDMITM CEC, PIP/PBP; Non Support: KVM Setup and use Secure the stand on a stable desk, or choose a compatible mount using the listed VESA pattern. Connect compatible power and video cables, then set resolution, refresh rate and HDR in the operating system and monitor menu. Maximum refresh rate can depend on the input, resolution, graphics hardware and cable; overclocked or dual-mode rates require the corresponding settings. Use USB and Type-C functions according to the specifications listed for this model.
