螢幕
MSI 微星 MAG 272QPW QD-OLED X28 螢幕
MSI MAG 272QPW QD-OLED X28 Monitor
MSI 微星 MAG 272QPW QD-OLED X28 螢幕，適合依畫面尺寸、解析度與更新率選擇顯示設備。面板與連接埠規格如下；不同輸入端子的最高解析度及更新率請依各項限制搭配。
產品特色
面板尺寸：26.5“
面板類型：QD-OLED
面板解析度：2560 x 1440 (WQHD)
更新率：280Hz
HDR 支援：VESA DisplayHDR True Black 400
完整規格
面板尺寸：26.5“
有效顯示區域（mm）：590.42 (H) x 333.72 (V)
曲率：平面
面板類型：QD-OLED
面板解析度：2560 x 1440 (WQHD)
像素間距：0.2292 (H) x 0.2292 (V)
螢幕比例：16:9
亮度：SDR: 250
HDR: 450 (典型值) (True Black 400 含 10% APL)
1000 (典型值) (峰值 1000 含 3% APL)
靜態對比度：1500000:1 (典型值)
訊號頻率：30~450.8KHz (H) / 48~280Hz (V)
更新率：280Hz
動態更新率技術：Adaptive-Sync
HDR 支援：VESA DisplayHDR True Black 400
影像連接埠：1x DisplayPort 1.4a (HBR3)
2x HDMI™ 2.1 (WQHD@280Hz)
1x Type-C (DP alt.) 含 15W Power Delivery 供電
音訊連接埠：1x 耳機輸出
可視角度：178° (H) / 178° (V)
Adobe RGB／DCI-P3／sRGB：98% / 99% / 138% (CIE1976 標準)
表面處理：抗反射
顯示色彩：1.07B,10 bits
電源輸入：100~240V, 50/60Hz
高度調整：0 ~ 110 mm
Kensington 鎖孔：支援
包裝尺寸（寬×深×高）：820 x 169 x 513 mm
(32.28 x 6.65 x 20.20 吋)
窄邊框設計：支援
VESA 安裝：100 x 100 mm
可變更新率範圍：48~280Hz
俯仰調整：-5° ~ 20°
遊戲主機模式：支援的解析度與更新率:
1080p: 60Hz 與 120Hz
1440p: 60Hz 與 120Hz
HDMI™ CEC: 支援
VRR: PS5 與 Xbox 支援
PIP／PBP 功能：支援
含支架尺寸（寬×深×高）：611.1 x 241.9 x 532.84 mm
(24.06 x 9.52 x 20.98 吋)
不含支架尺寸（寬×深×高）：611.1 x 69.3 x 357.2 mm
(24.06 x 2.73 x 14.06 吋)
淨重／毛重：6.8 kg (14.99 lbs) / 10.49 kg (23.13 lbs)
配件：1x DisplayPort 線材 (1.4a), 1x 電源線 (C13), 1x 快速指南, 4x VESA 壁掛螺絲
備註：Display Port: 2560 x 1440 (最高可達 280Hz)
HDMI™: 2560 x 1440 (最高可達 280Hz)
Type-C (DP alt.): 2560 x 1440 (最高可達 280Hz)
支援: HDMI™ CEC, PIP/PBP; 不支援: KVM
使用與安裝
將底座固定於穩固桌面，或依列示的 VESA 孔距選擇相容支架。連接適用的電源及影像線材，在作業系統與螢幕選單設定所需解析度、更新率及 HDR。最高更新率可能因輸入端子、解析度、顯示卡及線材而受限；超頻或雙模式數值須使用對應設定。USB 與 Type-C 功能依本型號列示的規格使用。
The MSI MAG 272QPW QD-OLED X28 monitor offers the panel and connectivity specifications below. Choose it by screen size, resolution and refresh rate, and match your connection to the stated resolution and refresh-rate limits for each input.
Features
Panel size: 26.5“
Panel type: QD-OLED
Panel resolution: 2560 x 1440 (WQHD)
Refresh rate: 280Hz
HDR support: VESA DisplayHDR True Black 400
Full specifications
Panel size: 26.5“
Active display area (mm): 590.42 (H) x 333.72 (V)
Curvature: Flat
Panel type: QD-OLED
Panel resolution: 2560 x 1440 (WQHD)
Pixel pitch: 0.2292 (H) x 0.2292 (V)
Aspect ratio: 16:9
Brightness: SDR: 250
HDR: 450 (Typ.) (True Black 400 with 10% APL)
1000 (Typ.) (Peak 1000 with 3% APL)
Contrast ratio: 1500000:1 (Typ.)
Signal frequency: 30~450.8KHz (H) / 48~280Hz (V)
Refresh rate: 280Hz
Dynamic refresh-rate technology: Adaptive-Sync
HDR support: VESA DisplayHDR True Black 400
Video ports: 1x DisplayPort 1.4a (HBR3)
2x HDMI™ 2.1 (WQHD@280Hz)
1x Type-C (DP alt.) w/ 15W Power Delivery
Audio ports: 1x Headphone-out
Viewing angle: 178° (H) / 178° (V)
Adobe RGB / DCI-P3 / sRGB: 98% / 99% / 138% (CIE1976 Standard)
Surface treatment: Anti-Reflection
Display colors: 1.07B,10 bits
Power input: 100~240V, 50/60Hz
Height adjustment: 0 ~ 110 mm
Kensington lock: Yes
Carton dimensions (W × D × H): 820 x 169 x 513 mm
(32.28 x 6.65 x 20.20 inch)
Frameless design: Yes
VESA mounting: 100 x 100 mm
Variable refresh-rate range: 48~280Hz
Tilt adjustment: -5° ~ 20°
Console mode: Supported Resolution & Refresh Rate:
1080p: 60Hz and 120Hz
1440p: 60Hz and 120Hz
HDMI™ CEC: Supported
VRR: PS5 and Xbox Supported
PIP/PBP function: Yes
Dimensions with stand (W × D × H): 611.1 x 241.9 x 532.84 mm
(24.06 x 9.52 x 20.98 inch)
Dimensions without stand (W × D × H): 611.1 x 69.3 x 357.2 mm
(24.06 x 2.73 x 14.06 inch)
Net/gross weight: 6.8 kg (14.99 lbs) / 10.49 kg (23.13 lbs)
Accessories: 1x DisplayPort Cable (1.4a), 1x Power Cord (C13), 1x Quick Guide, 4x VESA Wall Mount Screw
Notes: Display Port: 2560 x 1440 (Up to 280Hz)
HDMI™: 2560 x 1440 (Up to 280Hz)
Type-C (DP alt.): 2560 x 1440 (Up to 280Hz)
Support: HDMI™ CEC, PIP/PBP; Non Support: KVM
Setup and use
Secure the stand on a stable desk, or choose a compatible mount using the listed VESA pattern. Connect compatible power and video cables, then set resolution, refresh rate and HDR in the operating system and monitor menu. Maximum refresh rate can depend on the input, resolution, graphics hardware and cable; overclocked or dual-mode rates require the corresponding settings. Use USB and Type-C functions according to the specifications listed for this model.
洽詢商品 歡迎透過 LINE 或來電，與我們確認規格及供貨資訊。
