MSI 微星 G255PF E2 螢幕
MSI G255PF E2 Monitor
MSI 微星 G255PF E2 螢幕，適合依畫面尺寸、解析度與更新率選擇顯示設備。面板與連接埠規格如下；不同輸入端子的最高解析度及更新率請依各項限制搭配。
產品特色
面板尺寸：24.5" (62.2cm)
面板類型：Rapid IPS
面板解析度：1920 x 1080 (FHD)
更新率：180Hz
反應時間：1ms (GtG)
完整規格
面板尺寸：24.5" (62.2cm)
有效顯示區域（mm）：543.744 (H) x 302.616 (V)
曲率：平面
面板類型：Rapid IPS
面板解析度：1920 x 1080 (FHD)
像素間距：0.2832(H) x 0.2802(V)
螢幕比例：16:9
亮度：300
靜態對比度：1000:1
動態對比度：100000000:1
訊號頻率：52.7KHz-198KHz / 48-180Hz(V)
更新率：180Hz
反應時間：1ms (GtG)
動態更新率技術：AMD FreeSync™
影像連接埠：1x Display Port (1.2a)
2x HDMI™ (2.0b)
音訊連接埠：1x 耳機輸出
2x 2W 喇叭
可視角度：178° (H) / 178° (V)
Adobe RGB／DCI-P3／sRGB：82% / 78% / 99%
表面處理：防眩光
顯示色彩：16.7M (8btis)
電源規格：電源線
電源輸入：100~240V, 50/60Hz
俯仰調整：-5 ~ 20°
高度調整：0 ~ 130mm
左右旋轉：-30° ~ 30°
垂直旋轉：-90° ~ 90°
Kensington 鎖孔：支援
尺寸（寬×深×高）：557.1 x 227.9 x 511.9mm
557.1 x 66.4 x 326.9mm (不含底座)
包裝尺寸（寬×深×高）：WW 紙箱: 630 x 142 x 508 mm
外箱: 648 x 160 x 538 mm
窄邊框設計：支援
VESA 安裝：100 x 100 mm
可變更新率範圍：48~180Hz
淨重／毛重：5.3kg / 7.8kg
2.87kg (不含底座)
備註：Display Port: 1920 x 1080 (最高可達 180Hz)
HDMI™: 1920 x 1080 (最高可達 180Hz)
Adobe RGB, DCI-P3 與 sRGB 依據 CIE1976 標準
使用與安裝
將底座固定於穩固桌面，或依列示的 VESA 孔距選擇相容支架。連接適用的電源及影像線材，在作業系統與螢幕選單設定所需解析度、更新率及 HDR。最高更新率可能因輸入端子、解析度、顯示卡及線材而受限；超頻或雙模式數值須使用對應設定。USB 與 Type-C 功能依本型號列示的規格使用。
The MSI G255PF E2 monitor offers the panel and connectivity specifications below. Choose it by screen size, resolution and refresh rate, and match your connection to the stated resolution and refresh-rate limits for each input.
Features
Panel size: 24.5" (62.2cm)
Panel type: Rapid IPS
Panel resolution: 1920 x 1080 (FHD)
Refresh rate: 180Hz
Response time: 1ms (GtG)
Full specifications
Panel size: 24.5" (62.2cm)
Active display area (mm): 543.744 (H) x 302.616 (V)
Curvature: Flat
Panel type: Rapid IPS
Panel resolution: 1920 x 1080 (FHD)
Pixel pitch: 0.2832(H) x 0.2802(V)
Aspect ratio: 16:9
Brightness: 300
Contrast ratio: 1000:1
Dynamic contrast ratio: 100000000:1
Signal frequency: 52.7KHz-198KHz / 48-180Hz(V)
Refresh rate: 180Hz
Response time: 1ms (GtG)
Dynamic refresh-rate technology: AMD FreeSync™
Video ports: 1x Display Port (1.2a)
2x HDMI™ (2.0b)
Audio ports: 1x Headphone out
2x 2W Speaker
Viewing angle: 178° (H) / 178° (V)
Adobe RGB / DCI-P3 / sRGB: 82% / 78% / 99%
Surface treatment: Anti-glare
Display colors: 16.7M (8btis)
Power: Power Cable
Power input: 100~240V, 50/60Hz
Tilt adjustment: -5 ~ 20°
Height adjustment: 0 ~ 130mm
Swivel adjustment: -30° ~ 30°
Pivot adjustment: -90° ~ 90°
Kensington lock: Yes
Dimensions (W × D × H): 557.1 x 227.9 x 511.9mm
557.1 x 66.4 x 326.9mm (without stand)
Carton dimensions (W × D × H): WW carton: 630 x 142 x 508 mm
Outer: 648 x 160 x 538 mm
Frameless design: Yes
VESA mounting: 100 x 100 mm
Variable refresh-rate range: 48~180Hz
Net/gross weight: 5.3kg / 7.8kg
2.87kg (without stand)
Notes: Display Port: 1920 x 1080 (Up to 180Hz)
HDMI™: 1920 x 1080 (Up to 180Hz)
Adobe RGB, DCI-P3 and sRGB follow CIE1976 Standard
Setup and use
Secure the stand on a stable desk, or choose a compatible mount using the listed VESA pattern. Connect compatible power and video cables, then set resolution, refresh rate and HDR in the operating system and monitor menu. Maximum refresh rate can depend on the input, resolution, graphics hardware and cable; overclocked or dual-mode rates require the corresponding settings. Use USB and Type-C functions according to the specifications listed for this model.
