螢幕
ASUS 華碩 ROG Strix XG248QSG Ace 電競螢幕
ASUS ROG Strix XG248QSG Ace
ROG Strix XG248QSG Ace 提供24.1 吋 Super TN面板、1920x1080 解析度、最高 610Hz 更新率，可用於電競顯示。
完整規格
螢幕
面板尺寸 :24.1
長寬比 :16:9
色彩飽和度 (DCI-P3) :90%
色彩飽和度 (sRGB) :125%
面板類型 :Super TN
真實解析度 :1920x1080
顯示畫面尺寸(HxV) :535.68 x 298.08 mm
顯示表面 :防眩光
畫素點距 :0.279mm
亮度 (典型值):350cd/㎡
亮度 (HDR, Peak):400 cd/㎡
對比率 :1000:1
可視角度 (CR≧10) :170°/ 160°
反應時間 :0.7ms(GTG), 0.1ms(min.)
色彩準確度:△E< 2
顯示色彩 :16.7M
不閃屏 :支援
HDR（高動態範圍）支援:HDR10
畫面更新率（最大值） :610Hz
特色
GamePlus:支援
Game Visual:支援
VRR Technology:G-SYNC® Compatible
Extreme Low Motion Blur:支援, ELMB 2
Shadow Boost:支援
ELMB Sync:支援
Aspect Control:支援
Color Calibration E-report:支援, via DisplayWidget Center
I/O連接埠
DisplayPort 1.4 DSCx 1
HDMI (v2.1)x 2
耳機插孔 :支援
聲音特色
揚聲器:不支援
訊號頻率
Digital 訊號 Frequency : HDMI: 27~851 KHz (H) / 24~610 Hz (V)
DisplayPort: 27~851 KHz (H) / 24~610 Hz (V)
耗電量
耗電量 : <24W
省電模式 : <0.5W
關機模式 : <0.3W
Voltage : 100-240V, 50/60Hz
機構設計
1/4" Tripod Socket : 支援
前後傾斜 :支援 (+35° ~ -5°)
左右旋轉 :支援 (+45° ~ -45°)
高度調整 :0~160mm
VESA 牆掛 :100x100mm
燈光效果 (Aura):Aura Sync
Kensington 防盜鎖孔 :支援
產品尺寸
Phys. Dimension with stand (W x H x D) : 55.7 x 51.4 x 18.8 cm (21.93" x 20.24" x 7.40")
Phys. Dimension without Stand (W x H x D) : 55.7 x 33.3 x 8.5 cm (21.93" x 13.11" x 3.35")
Box Dimension (W x H x D) : 74.2 x 22.8 x 41.4 cm (29.21" x 8.98" x 16.30")
重量
Net Weight with Stand : 5.6 kg (12.35 lbs)
Net Weight without Stand : 3.3 kg (7.28 lbs)
Gross Weight : 8.2 kg (18.08 lbs)
配件
DisplayPort 傳輸線\nPower adapter\nPower cord\nQuick start guide\nROG pouch\nROG sticker\n保固卡
安規認證
TÜV 不閃屏\nTÜV Low Blue Light\nVESA DisplayHDR 400 \nAMD FreeSync Premium\nG-SYNC Compatible
ROG Strix XG248QSG Ace offers a 24.1-inch Super TN panel, 1920x1080 resolution, a refresh rate of up to 610Hz for gaming.
Full specifications
Display
Panel Size (inch) :24.1
Aspect Ratio :16:9
Color Space (DCI-P3) :90%
Color Space (sRGB) :125%
Panel Type :Super TN
Resolution :1920x1080
Display Viewing Area (HxV) :535.68 x 298.08 mm
Display Surface :Anti-Glare
Pixel Pitch :0.279mm
Brightness (Typ.) :350cd/㎡
Brightness (HDR, Peak) * :400 cd/㎡
Contrast Ratio (Typ.) :1000:1
Viewing Angle (CR≧10) :170°/ 160°
Response Time :0.7ms(GTG), 0.1ms(min.)
Color Accuracy:△E< 2
Display Colors :16.7M
Flicker free :Yes
HDR (High Dynamic Range) Support :HDR10
Refresh Rate (max) :610Hz
Features
GamePlus:Yes
Game Visual:Yes
VRR Technology:G-SYNC® Compatible
Extreme Low Motion Blur:Yes, ELMB 2
Shadow Boost:Yes
ELMB Sync:Supported
Aspect Control:Yes
Color Calibration E-report:Yes, via DisplayWidget Center
I/O Ports
DisplayPort 1.4 DSCx 1
HDMI (v2.1)x 2
Earphone Jack :Yes
Audio
Speaker:No
Signal Frequency
Digital Signal Frequency : HDMI: 27~851 KHz (H) / 24~610 Hz (V)
DisplayPort: 27~851 KHz (H) / 24~610 Hz (V)
Power Consumption
Power Consumption : <24W
Power Saving Mode : <0.5W
Power Off Mode : <0.3W
Voltage : 100-240V, 50/60Hz
Mechanical Design
1/4" Tripod Socket : Yes
Tilt :Yes (+35° ~ -5°)
Swivel :Yes (+45° ~ -45°)
Height Adjustment :0~160mm
VESA Wall Mounting :100x100mm
Lighting effect (Aura) :Aura Sync
Kensington Lock :Yes
Dimensions (Esti.)(vary by regions)
Phys. Dimension with stand (W x H x D) : 55.7 x 51.4 x 18.8 cm (21.93" x 20.24" x 7.40")
Phys. Dimension without Stand (W x H x D) : 55.7 x 33.3 x 8.5 cm (21.93" x 13.11" x 3.35")
Box Dimension (W x H x D) : 74.2 x 22.8 x 41.4 cm (29.21" x 8.98" x 16.30")
Weight (Esti.)(vary by regions)
Net Weight with Stand : 5.6 kg (12.35 lbs)
Net Weight without Stand : 3.3 kg (7.28 lbs)
Gross Weight : 8.2 kg (18.08 lbs)
Accessories (vary by regions)
DisplayPort cable\nPower adapter\nPower cord\nQuick start guide\nROG pouch\nROG sticker\nWarranty Card
Certificate
TÜV Flicker-free\nTÜV Low Blue Light\nVESA DisplayHDR 400 \nAMD FreeSync Premium\nG-SYNC Compatible
