機殼
MONTECH 君主 TEN 黑色 機殼
MONTECH TEN Black PC Case
TEN 是具三種核心配置的模組化機殼，採高透氣網孔外觀。M1著重風冷配置，M2提供頂部水冷路徑，I3採Mini-ITX與較精簡的主機板配置。三種模式共用外殼，但CPU散熱器、電源、硬碟及水冷位置限制不同，組裝前應先選模式，再確認顯示卡方向與水冷位置。隨附一顆92mm後風扇。
尺寸（長×寬×高）：骨架420×185×293mm（22.7L）；不含突起物442×196.5×326.05mm（28.3L）；含突起物456×196.5×327.65mm（29.3L）。外箱505×260×395mm。
主機板：M1/M2支援Micro-ATX及Mini-ITX；I3僅Mini-ITX。
CPU散熱器限高：M1/M2為155mm；I3為52mm。
顯示卡長度：M1水平425mm、垂直410mm；M2/I3水平或垂直均410mm。
PCIe槽位：水平4槽、垂直3槽。
電源：M1/M2支援ATX、SFX-L、SFX（前方或主機板支架）；I3僅SFX-L、SFX（主機板支架）。官網未列電源長度上限。
硬碟最大數量：M1/M2為3.5吋HDD 2顆、2.5吋SSD 4顆；I3不列3.5吋HDD支援，2.5吋SSD最多3顆。
風扇：三模式頂部、側邊、底部各支援120mm×3或140mm×2；後方92mm×1（已附）。I3側風扇空間依顯示卡尺寸而定。
水冷：支援位置的冷排尺寸均列120/140/240/280/360mm。M1可側裝（水平顯示卡）或底裝（垂直顯示卡），不列頂裝。M2/I3可頂裝（垂直顯示卡）或側裝（水平顯示卡），不列底裝。以上依官網配置表列示，須按模式及安裝指南核對組件干涉。
I/O：電源鍵、USB 3.0×2、Type-C 20G×1、耳麥二合一孔×1。
防塵：底部濾網。官方原廠標示保固：1年。
注意：容量依量測是否含外板及突起物而不同；各項最大值不保證能同時達成，尤其須確認顯示卡、電源、側風扇和冷排的共享空間。官網另介紹十週年紀念配件，實際供貨內容應依所購版本確認。
本商品顏色：黑色。圖片中的主機板、顯示卡及其他裝機配件為示意；隨附風扇以本商品規格為準。
TEN is a modular mesh enclosure with three core layouts. M1 emphasizes air cooling, M2 provides a top liquid-cooling route, and I3 uses a Mini-ITX arrangement. The shell is shared, but CPU cooler, PSU, storage and radiator restrictions vary by mode. Choose the layout before selecting GPU orientation and radiator position. One rear 92 mm fan is included.
Dimensions (L × W × H): bare frame 420 × 185 × 293 mm (22.7 L); excluding protrusions 442 × 196.5 × 326.05 mm (28.3 L); including protrusions 456 × 196.5 × 327.65 mm (29.3 L). Carton: 505 × 260 × 395 mm.
Motherboards: M1/M2 support Micro-ATX and Mini-ITX; I3 supports Mini-ITX only.
CPU cooler height: 155 mm in M1/M2; 52 mm in I3.
GPU length: M1 supports 425 mm horizontally or 410 mm vertically; M2/I3 list 410 mm for either orientation.
PCIe slots: four horizontal and three vertical.
PSU: M1/M2 support ATX, SFX-L and SFX at the front or motherboard bracket; I3 supports SFX-L and SFX at the motherboard bracket. A maximum PSU length is not listed.
Maximum drive counts: M1/M2 list two 3.5-inch HDDs and four 2.5-inch SSDs; I3 lists no 3.5-inch HDD support and up to three 2.5-inch SSDs.
Fan mounts: all modes list three 120 mm or two 140 mm fans at each of the top, side and bottom, plus one rear 92 mm fan (included). I3 side-fan clearance depends on GPU dimensions.
Radiators: supported locations list 120/140/240/280/360 mm sizes. M1 lists side mounting with a horizontal GPU or bottom mounting with a vertical GPU, with no top radiator support. M2/I3 list top mounting with a vertical GPU or side mounting with a horizontal GPU, with no bottom radiator support. These conditions follow the manufacturer's configuration table; consult the installation guide for component interference in the selected mode.
I/O: power button, two USB 3.0 ports, one Type-C 20G port and one combination audio jack.
Dust filter: bottom. Manufacturer warranty: one year.
Build notes: Volume changes depending on whether panels and protrusions are included. Individual maxima are not guaranteed simultaneously; check shared space between the GPU, PSU, side fans and radiator. The page also describes anniversary accessories; confirm the package supplied with the purchased version.
This listing: Black. Motherboards, graphics cards and other build components shown in photos are for illustration; included fans are specified above.
